◆物品優缺點 Product features
1. 設(she)計構思(si)有意思(si),外觀(guan)簡約時尚大方,干凈(jing)效用(yong)好;
2. 調節器式颶風(feng)區(qu)分器,能將可(ke)以用(yong)在爐料與(yu)很小塵(chen)土區(qu)分,好的爐料堅(jian)持運行;
3. 通常(chang)零(ling)(ling)部分按照質量上乘進囗的所需要的零(ling)(ling)部件,的使用(yong)壽命短長(chang);
4. 手工(gong)加(jia)工(gong)零部件從表面平滑;
5. 多功位定制;實操員可互相實操噴砂。只能根據加盟商訴求,可以擇人工操作或主動 ;可按合作方的標準定制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆實用范圍內 Applicable scope
原(yuan)材(cai)料,電子產品表(biao)殼,車(che)載音響開關按鈕(niu),漢堡(bao)包烤盤等(deng)正等(deng)軸(zhou)測圖及方體鋼件(jian)的噴砂生產。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆最主要技術性能指標 Main technical parameters
|
機規(gui)格(ge)型號 Model |
STR-多工位輸送式噴砂機 |
|
整體長寬(kuan)高 Complete machine size(mm) |
3000×1000×1700 |
|
操作個人空間(jian) Work space(mm) |
2000×1000×800 |
|
外傳送尺(chi)寸圖 Conveying the size(mm) |
500×1000×1000(2件) |
|
清灰箱長寬比 Dedust box sizes(mm) |
600×600×1800 |
|
分離(li)器高壓(ya)電機 Separator motor |
220V 50HZ 550W |
|
破乳器新(xin)風量 Separator air volume |
8.5m3/min |
|
壓縮的水汽源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明(ming) Floodlight |
兩盞30W防爆型燈 |
|
刷(shua)卡機載重量 Machine weight |
550kg |
